Bearing specifications
61918
Deep Groove Ball Bearing
- HCT SKU
- HCT-005616
- Series
- 61900
- Configuration
- Single row · Open · CN
- Bore (d) 90 mm
- Outside (D) 125 mm
- Width (B) 18 mm
- Dynamic load (C) 33.2 kN
pcs
Overview
HCT Bearings supplies the 61918 deep groove ball bearing (90 mm bore x 125 mm outside diameter x 18 mm width). Factory-direct sourcing with complete dimensional and load-rating data available on this page. Request a quote for volume pricing, lead time and availability.
Bearing designation
Designation breakdown for 61918.
- 61918 Basic designation series 61900 · bore code 18, 90 mm
Product information
Units
Dimensions and mass
| Bore diameter (d) | 90 mm |
|---|---|
| Outer diameter (D) | 125 mm |
| Width (B) | 18 mm |
Basic load ratings
| Dynamic load rating (C) | 33.2 kN |
|---|---|
| Static load rating (C0) | 31.5 kN |
Speeds
| Reference speed | 11 000 r/min |
|---|---|
| Limiting speed | 6 700 r/min |
Design and properties
- Seal / Shield
- Open
- Internal Clearance
- CN normal
- Cage
- Sheet metal
- Rows
- Single row
- Material
- Bearing steel
Converted values are shown for convenience only. The metric figures are the published data.
Specifications are provided for product selection and may vary by configuration. Please contact us for confirmation before ordering.
