Bearing specifications
1202
Self-Aligning Ball Bearings
- HCT SKU
- HCT-055814
- Brand
- KOYO
- Configuration
- CN
- Bore (d) 15 mm
- Outside (D) 35 mm
- Width (B) 11 mm
- Dynamic load (C) 9.35 kN
pcs
Overview
Bearing designation
Designation breakdown for 1202.
- 1202 Basic designation bore code 02, 15 mm
Product information
Units
Dimensions and mass
| Bore diameter (d) | 15 mm |
|---|---|
| Outer diameter (D) | 35 mm |
| Width (B) | 11 mm |
Basic load ratings
| Dynamic load rating (C) | 9.35 kN |
|---|---|
| Static load rating (C0) | 1.75 kN |
Design and properties
- Internal Clearance
- CN normal
- Cage
- STEEL
- Material
- BEARING_STEEL
Converted values are shown for convenience only. The metric figures are the published data.
Specifications are provided for product selection and may vary by configuration. Please contact us for confirmation before ordering.
