Bearing specifications
02872 / 02820
Tapered Roller Bearings
- HCT SKU
- HCT-048960
- Brand
- TIMKEN
- Configuration
- CN
- Bore (d) 28.575 mm
- Outside (D) 73.025 mm
- Width (B) 22.225 mm
- Dynamic load (C) 65.7 kN
pcs
Overview
Bearing designation
Designation breakdown for 02872 / 02820.
- 02872 Basic designation
- / 02820 —
Product information
Units
Dimensions and mass
| Bore diameter (d) | 28.575 mm |
|---|---|
| Outer diameter (D) | 73.025 mm |
| Width (B) | 22.225 mm |
Basic load ratings
| Dynamic load rating (C) | 65.7 kN |
|---|---|
| Static load rating (C0) | 74.9 kN |
Design and properties
- Internal Clearance
- CN normal
- Cage
- STEEL
- Material
- BEARING_STEEL
Converted values are shown for convenience only. The metric figures are the published data.
Specifications are provided for product selection and may vary by configuration. Please contact us for confirmation before ordering.
